DGN Film is a Professional Plastic & Heat Shrinkable Film Manufacturer since 2005.

35mic-50mic PETG Clear Heat Shrink Film For Shrink Labels DGN213 1

35mic-50mic PETG Clear Heat Shrink Film For Shrink Labels DGN213 2

35mic-50mic PETG Clear Heat Shrink Film For Shrink Labels DGN213 3

35mic-50mic PETG Clear Heat Shrink Film For Shrink Labels DGN213 4

35mic-50mic PETG Clear Heat Shrink Film For Shrink Labels DGN213 5

35mic-50mic PETG Clear Heat Shrink Film For Shrink Labels DGN213

Model:

DGN213

MOQ:

2000KGS

Payment Term:

T/T, L/C

Delivery time:

About 7 -15 Working Days

Port Of Lading:

SHENZHEN

Certification:

Reach, RoHs, Food Contact

Thickness:

30-50mic

Color:

Transaparent

Inquiry

Write a Review

35mic-50mic PETG Clear Heat Shrink Film For Shrink Labels DGN213 6

35mic-50mic PETG Clear Heat Shrink Film For Shrink Labels DGN213 7

Product Introduction

PETG- Polypropylene Terephthalate Glycol (PETG) shrink film
1) Up to 78% shrink
2) PETG starts to shrink between 158°F and 176°F
3) Highest level of clarity
4) Most commonly used for our Energy Drink Shrink Labels

PET/PETG Shrink Films (DGN213)- is the Label Film printing material which is widely used for wrap full of the bottle with the feature of high tensile strength, good flatness and fit for wide printing, perfect printing performance for shallow network printing Even and high shrinkage and excellent thermal shrinking stability. Widely used for bottle (big diameter difference between bottleneck and body) film labelling, eg.beverage bottles packaging , cleaning and bathing products packaging and cosmetics packaging.

Product Parameters

Name	PETG Shrink Film
Product number	DGN213
Brand	DGN
Material	PETG (Glycol-modified Polyetthylene Teraphthalate)
Thickness	30mic - 50mic
Width	350mm - 1200mm
Width Tolerance	±5%
Average Thickness Tolerance	±10%
Density	1.32 g/cm³
Color	Transparent
Supply Ability	12,000 Tons Per Year

35mic-50mic PETG Clear Heat Shrink Film For Shrink Labels DGN213 8

35mic-50mic PETG Clear Heat Shrink Film For Shrink Labels DGN213 9

35mic-50mic PETG Clear Heat Shrink Film For Shrink Labels DGN213 10

Product Characteristics

Physical Property	High shrink rate: . Flushes beautifully against complex contoured surfaces and tight fit remains over time. . Reaches maximum shrinkage potential more quickly than competitive products(up to 78% ultimate shrinkage) . Higher shrinkage reached at lower temperatures-great for heat sensitive products
	Very High Gloss Percentage : Smooth, transparent, and glossy
	Excellent Scuff Resistant : . Highly durable, excellent shock and tear resistant
	The Most Heat Resistant material : . Most resistant to heat. Higher shrinking temperature than PVC
	The Best Shrinkage Performance : . Best shrinkage performance. Stable shrinkage with no waves or wrinkles.
Environmental Health	Eco - Friendly and Easily Recycled : . Eco-friendly and recyclable.

35mic-50mic PETG Clear Heat Shrink Film For Shrink Labels DGN213 11

35mic-50mic PETG Clear Heat Shrink Film For Shrink Labels DGN213 12

Technical Data Sheet

Excellent Smoothness. Great Printing Effect

PETG透明-DGN213

Properties		Unit	Data		Test Method
Thickness (Tolerance : ±10%)		μm	35~50		ASTM D374
Density		g/c㎡	1.32		ASTM D792
Haze		%	3.65		ASTM D1003
Gloss(45°)		-	110		ASTM D2457
Dyne		mN/m	40		ASTM D2578
Yield		㎡/kg	35μm	21.6	--
			40μm	18.9
			45μm	16.8
			50μm	15.2
Coefficient of Friction	μs	-	0.485		ASTM D1894E
	μk		0.43
Tensile Strength	MD	Mpa	50		ASTM D882 V=100mm/min
	TD		240
Elongation At Break	MD	%	430
	TD		390.84
Heat Shrinkage (Tolerance : ±3%)	60℃	%	0	0	ASTM D1204
	70℃		0	10
	80℃		-4	58
	90℃		0	72
	100℃		2	78

35mic-50mic PETG Clear Heat Shrink Film For Shrink Labels DGN213 14

Product Advantages

For over 10 years we have dedicated ourselves to nature and its uniqueness.

35mic-50mic PETG Clear Heat Shrink Film For Shrink Labels DGN213 15

Excellent High Shrinkage Rate

Shrinkage rate of up to 78% with shrinking temperature starting at 70-80 degrees Celsius.

35mic-50mic PETG Clear Heat Shrink Film For Shrink Labels DGN213 16

Excellent Print-ability

Our PETG shrink film has good printing performance, clear patterns with bright colors and strong layers can be printed, which makes your shrink sleeve labels more attractive.

35mic-50mic PETG Clear Heat Shrink Film For Shrink Labels DGN213 17

Crystal Clarity

The clarity of this film enables eye catching graphics when printed.

35mic-50mic PETG Clear Heat Shrink Film For Shrink Labels DGN213 18

Stable Shrinkage

With stable shrinkage, it can improve your work efficiency and reduce wastage, making it earier in labeling.

35mic-50mic PETG Clear Heat Shrink Film For Shrink Labels DGN213 19

Excellent Optically

The clarity of this film enables eye catching graphics when printed.

35mic-50mic PETG Clear Heat Shrink Film For Shrink Labels DGN213 20

Product Application

35mic-50mic PETG Clear Heat Shrink Film For Shrink Labels DGN213 21

35mic-50mic PETG Clear Heat Shrink Film For Shrink Labels DGN213 22

35mic-50mic PETG Clear Heat Shrink Film For Shrink Labels DGN213 23

35mic-50mic PETG Clear Heat Shrink Film For Shrink Labels DGN213 24

35mic-50mic PETG Clear Heat Shrink Film For Shrink Labels DGN213 25

35mic-50mic PETG Clear Heat Shrink Film For Shrink Labels DGN213 26

Due to DGN213’s high shrinkage, it is suitable for packaging with unique or curvy shape, especially bottles with high and narrow neck like wine bottles.

1) Full or partial body shrink sleeves
2) Full or partial body roll sleeves
3) Multi-packs
4) Tamper-evident bands
5) Wine capsules and disk plates
