    PRODUCT INTRODUCTION

    PETG-2031: is a new high-performing light blocking label film- PETG white shrink film, which introduces maximum light blocking properties into the film process and satisfies the market need for films that are cost-effective, process efficient and improve light barrier characteristics. Exhibiting ultimate shrinkage values over 55% to nearly 60%, it is suitable for a wide range of container geometries and printing methods (ROTO-GRAVURE to FLEXO PRESS) and offer the most suitable performing shrink percentages for optimal design freedom while eliminating the need for high-barrier primary containers.

    Product Parameters

    Name

    PETG Shrink Film

    Product number

    PETG-2031

    Brand

    HYF

    Material

    PETG (Glycol-modified Polyetthylene Teraphthalate)

    Thickness

    30mic - 50mic

    Width

    350mm - 1200mm

    Width Tolerance

    ±5%

    Average Thickness Tolerance

    ±10%

    Density

    1.32 g/cm³

    Color

    Transparent

    Supply Ability

    12,000 Tons Per Year

    35mic-50mic Low Shrinkage PETG White Shrink Film PETG-2031 7
    35mic-50mic Low Shrinkage PETG White Shrink Film PETG-2031 8
    35mic-50mic Low Shrinkage PETG White Shrink Film PETG-2031 9

    Product Characteristics

    HYF’s PETG white shrink film affords a unique blend of benefits across applications, including:

    1) Reduced total package costs (replaces HDPE multi-wall primary containers)

    2) Light-blocking
    - With transmission rate of <1%

    3) Extended shelf life
    - For dairy, juice, organic and organic beverages

    4) Vitamin protection
    - Dairy products

    5) Off-taste reduction (dairy products)
    - Dairy products

    6) Color protection

    35mic-50mic Low Shrinkage PETG White Shrink Film PETG-2031 10

    Technical Data Sheet

    35mic-50mic Low Shrinkage PETG White Shrink Film PETG-2031 11

    Properties

    Unit

    Data

    Test Method

    Thickness (Tolerance : ±10%)

    μm

    35~50

    ASTM D374

    Tensile Strength

    MD

    Mpa

    ≥40

    ASTM D882 V=100mm/min

    TD

    ≥200

    Elongation At Break

    MD

    %

    ≥400

    TD

    ≥35

    Heat Shrinkage (Tolerance : ±3%)

    60℃

    %

    0

    0

    ASTM D1204

    70℃

    0

    3.4

    80℃

    0.1

    40.2

    90℃

    0.6

    53

    100℃

    3.9

    59.2

    Density

    g/㎤

    1.45

    ASTM D792

    Haze

    %

    ≥70

    ASTM D1003

    Gloss(45℃)

    -

    ≤30

    ASTM D2457

    Dyne

    mN/m

    40

    ASTM D2578

    Yield

    ㎡/kg

    35㎛

    19.7

    --

    40㎛

    17.2

    45㎛

    15.3

    50㎛

    13.8

    Coefficient of Friction

    μs

    -

    ≤0.60

    ASTM D1894E

    μk

    0.55

    Product Advantage

    35mic-50mic Low Shrinkage PETG White Shrink Film PETG-2031 12
    More than 80% Opacity
    The high opacity of white PETG shrink film is important so that the light does not spoil the content too quickly - a longer shelf life is achieved with the opaque sleeve.
    35mic-50mic Low Shrinkage PETG White Shrink Film PETG-2031 13
    Stable Shrinkage
    Our PETG White shrink film has stable shrinkage, which make the perfect seam line in the shrink sleeve labels after bottling.
    35mic-50mic Low Shrinkage PETG White Shrink Film PETG-2031 14
    Excellent Print-ability
    Our PETG White shrink film has good printing performance, which can print clear patterns with bright colors and strong layers, making your shrink sleeve labels more attractive.
    35mic-50mic Low Shrinkage PETG White Shrink Film PETG-2031 15
    Low Shrinkage ( less than 60%)
    Low shrinkage is just for the normal bottle, almost no different from the top to the end of the bottle.
    35mic-50mic Low Shrinkage PETG White Shrink Film PETG-2031 16

    Product Application

    PETG white shrink film could be produced to all kinds of opaque shrink sleeve labels, which provide light-barrier protection for food, beverages, nutraceuticals, vitamins, supplements and other light-sensitive consumer packaged products. It is widely used in the following industries:

    - Beverage
    - Dairy
    - Juices
    - Organic beverages
    - Isotonics
    - Food
    - Health and beauty
    - Home and garden
    - Household
