PETG-2032 Opaque White PETG Heat Shrink Film 35mic-50mic 1

PETG-2032 Opaque White PETG Heat Shrink Film 35mic-50mic 2

PETG-2032 Opaque White PETG Heat Shrink Film 35mic-50mic 3

PETG-2032 Opaque White PETG Heat Shrink Film 35mic-50mic 4

PETG-2032 Opaque White PETG Heat Shrink Film 35mic-50mic

Model:

PETG-2032

MOQ:

5000KGS

Payment Term:

T/T, L/C

Delivery time:

About 10-20 Working Days

Port Of Lading:

Shanghai

Certification:

Reach, RoHs, Food Contact

Inquiry

Write a Review

PETG-2032 Opaque White PETG Heat Shrink Film 35mic-50mic 5

PETG-2032 Opaque White PETG Heat Shrink Film 35mic-50mic 6

PRODUCT INTRODUCTION

PETG-2032: Opaque white polyethylene terephthalate (PETG) shrink film from HYF offers up to 99% UV and visible light protection, enhances sustainability and provides cost savings. Exhibiting ultimate shrinkage values about 70%, displaying excellent printability and user-friendliness in the shrinkage tunnel, PETG-2032 is a great choice for a wide range of full-body labeling application.

Product Parameters

Name	PETG Shrink Film
Product number	PETG-2032
Brand	HYF
Material	PETG (Glycol-modified Polyetthylene Teraphthalate)
Thickness	30mic - 50mic
Width	350mm - 1200mm
Width Tolerance	±5%
Average Thickness Tolerance	±10%
Density	1.32 g/cm³
Color	Transparent
Supply Ability	12,000 Tons Per Year

PETG-2032 Opaque White PETG Heat Shrink Film 35mic-50mic 7

PETG-2032 Opaque White PETG Heat Shrink Film 35mic-50mic 8

PETG-2032 Opaque White PETG Heat Shrink Film 35mic-50mic 9

Product Characteristics

HYF’s PETG white shrink film affords a unique blend of benefits across applications, including:

- Light-blocking with transmission rates of < 1%
- Maintains vitamin protection
- Maintains product color
- Whitest film (gloss) compared to current options
- No multiple flood coat printing required to achieve light blocking characteristics
- Prints and seams like PETg
- Higher modulus for easy application

PETG-2032 Opaque White PETG Heat Shrink Film 35mic-50mic 10

Technical Data Sheet

PETG-2032 Opaque White PETG Heat Shrink Film 35mic-50mic 11

Properties	Unit	Data	Test Method
Thickness (Tolerance : ±10%)	μm	35~50	ASTM D374
Tensile Strength	MD	Mpa	≥35		ASTM D882 V=100mm/min
	TD		≥150
Elongation At Break	MD	%	≥300
	TD		≥40
Heat Shrinkage (Tolerance : ±3%)	60℃	%	0	0	ASTM D1204
	70℃		0	2.7
	80℃		0.2	40.1
	90℃		0.7	61.8
	100℃		4.6	69.2
Density		g/㎤	1.45		ASTM D792
Haze		%	≥70		ASTM D1003
Whiteness		-	≤30		ASTM D2457
Dyne		mN/m	40		ASTM D2578
Yield		㎡/kg	35㎛	19.7	--
			40㎛	17.2
			45㎛	15.3
			50㎛	13.8
Coefficient of Friction	μs	-	≤0.60		ASTM D1894E
	μk		0.55

Product Advantage

PETG-2032 Opaque White PETG Heat Shrink Film 35mic-50mic 12

More than 80% Opacity

White PETG shrink film with high opacity is very important, then the light does not spoil the content too quickly - a longer shelf life is achieved with the opaque sleeve.

PETG-2032 Opaque White PETG Heat Shrink Film 35mic-50mic 13

Middle Shrinkage (60% - 70%)

This shrinkage can meet most of different bottles.

PETG-2032 Opaque White PETG Heat Shrink Film 35mic-50mic 14

Stable Shrinkage

From the seamline in the shrink sleeve label after labeling, you can see how stable shrinkage the PETG shrink film is.

PETG-2032 Opaque White PETG Heat Shrink Film 35mic-50mic 15

Excellent Print-ability

Our PETG White shrink film has good printing performance, which can print clear patterns with bright colors and strong layers, making your shrink sleeve labels more attractive.

PETG-2032 Opaque White PETG Heat Shrink Film 35mic-50mic 16

Product Application

Same as transparent PETG shrinkable film, PETG white shrink film could be produced to various of opaque shrink sleeve labels. Compared transparent PETG shrink label film with whit ink, White opaque PETG shrink film can provide light-barrier protection for food, beverages, nutraceuticals, vitamins, supplements and other light-sensitive consumer packaged products. It is widely used in the following industries:

- Beverage
- Dairy
- Juices
- Organic beverages
- Isotonics
- Food
- Health and beauty
- Home and garden
- Household
